Single Spot Technology
The Amogh Smart is the green laser photocoagulator system designed with precision to treat retinal disorders using a single spot technology. Its effective touch screen interface allows easy access to the entire system, providing efficient treatment to the patients.
Efficient Workflow
The in-built user interface and the LCD touch screen display allows quick access to the treatment parameters providing extremely fast treatment with instant reports, thus maximizing the workflow efficiently.
Solid-State Technology
The patented solid-state technology in Amogh Smart ensures stable laser output providing reliable therapeutic laser beam for treating retinal diseases
Unique Joystick
The electronic micro manipulator on the joystick ensures the ultimate in controlled safety. The motorized joystick provides an ease of use to the surgeon, allowing an increased level of comfort during treatment.
Maximum Focus
The precise guidance of the aiming beam and the therapy beam guarantees optimum illumination on the site of treatment at all times whether it is in the far periphery or in the vicinity of the macula.
Safety Filters
True color and permanently inbuilt safety filters enable comfortable physician’s view and eliminates color distortion.
Magnificent Operative Design
The Amogh Smart provides an additional advantage to the users by providing LED illumination in the fiber optic cable connecting port, foot pedal & ON/OFF switch for their easy identification in the dark room. It also has an integrated voice confirmation technology providing better guidance to the user.
Laser Indirect Ophthalmoscope (Optional Delivery System)
Amogh Smart is designed with LIO compatibility, which is ideal for patients who are best examined and can be treated in supine position, including neonates, small children, and disabled patients. The major advantage of this is it has a variable focus option which provides improved diagnosis.
Other Features:
Vertical movement adjustment for illumination beam
Ultra view inbuilt eye safety laser filters provides a crystal clear view of developing lesions
A coaxial system of laser aiming beam along with white light illumination gives comfortable treatment
LIO can be made compatible for other selected lasers
True focus optical system
Small pupil adjustment
Endoprobes For Ophthalmic Endophotocoagulation (Optional Delivery System)
These disposable probes have a perfect ergonomic design and straight & curved/angled tips that are pre-sterilized. It provides an easy entry through small-gauge cannulas, and its tapered curve provides excellent laser energy delivery.
Other Features:
Available in 20G, 23G 25G & 27G series
Compatible for other selected laser photocoagulators
Reliable spot placement at far periphery
Footswitch
Compact and convenient foot switch
Technical Specification Of Green Laser Single Spot (GLS 532nm)
AMOGH SMART
| Parameter | Specification |
|---|---|
| Treatment Laser Type | Diode pumped, frequency doubled, true CW, solid-state |
| Laser Module Capacity | 3 Watts |
| Aiming Beam | 635 nm semiconductor diode laser, 0–1 mW (variable) |
| Power Adjustment Range | 10 mW – 1500 mW (variable) |
| Power Input | 100–240 V AC, 50–60 Hz, 2 A |
| Cooling System | Thermoelectric cooling (Peltier) and air-cooled |
| Operation Modes | Single pulse, repeat pulse, continuous mode |
| Screen Display | LCD touch screen |
| Laser Lifetime | 10,000 working hours |
| Dimensions (H × W × D) | 290 mm × 175 mm × 365 mm |
| Weight | 8 kg (without packing) |
| Power Consumption | 100 Watts |
| Pulse Duration | 10 ms – 10 seconds |
| Pulse Interval | 10 ms – 10 seconds |
| Treatment Laser Safety Class | Class IV |
Technical Specification Of Integrated Laser Slit Lamp (ILS)
| Parameter | Specification |
|---|---|
| Laser Spot Diameter | Adjustable from 50 – 1000 µm |
| Eyepiece | 12.5× |
| Magnification | 6×, 10×, 16×, 25×, 40× |
| Standard Slits | 0°, 45°, 135° |
| Illumination | 12 V – 30 W halogen lamp, variable brightness |
| Slit Length Adjustment | 1, 3, 5, 8, 10, 14 mm |
| Slit Width Adjustment | Continuously adjustable from 0 – 14 mm |
| Interpupillary Distance | 55 – 75 mm |
| Micro Manipulator | Electronic micro manipulator integrated in joystick |
| Working Distance | 120 mm (compatible with all laser contact lenses) |
| Power Input | 100–240 V AC, 50–60 Hz, 2.5 A |
| Filters | Yellow, Green (Red-free), Cobalt Blue |
| Laser Spot Size Display | 7-segment LED |
| Micro-Manipulation Movement | 360° |
| Power Consumption | 65 Watts |
| Laser Beam Delivery | Coaxial delivery with slit illumination |
| Movement Range – Longitudinal (In/Out) | 99 mm |
| Movement Range – Lateral (Left/Right) | 118 mm |
| Movement Range – Vertical (Up/Down) | 30 mm |
| Chin Rest Range | 90 mm |
| Dimensions (L × W × H) | 530 × 380 × 600 mm |
| Weight | 10 kg |
Technical Specification Of Laser Indirect Ophthalmoscope (LIO)
| Parameter | Specification |
|---|---|
| LIO Illumination | LED, 1 Watt |
| Output | 3.3 V DC, 700 mAh |
| Standard Spot Size | 200 µm on the retina |
| Standard Working Distance | 350 mm |
| Variable Spot Size (with Working Distance) | ≈ 181 µm (300 mm) to ≈ 550 µm (700 mm) on the retina |
| Laser Safety Filter | Permanently fixed, ultra-clear view |
| Illumination Field | Clear circular |
| Optical System | Stereoscopic |
| Pupillary Distance | 55 – 75 mm |
| Aperture Size | 4.0 mm, 3.0 mm, 1.2 mm |
| Image Size | 80.0 mm, 60.0 mm, 25.0 mm |
| Intensity Control | Continuously variable |
| Standard Filters | Yellow, White, Cobalt Blue |
| Power Consumption | 2 Watts |
| Power Input | 100–240 V AC, 50–60 Hz, 2 A |
| Weight | Approx. 700 grams |
| Dimensions (Standard Packing Foam Bag) | 230 × 520 × 450 mm |
