Product Overview
The APPA SCAN MAX-AP Ophthalmic Ultrasound Scanner with Pachymeter is a comprehensive diagnostic system designed to deliver accurate ocular ultrasound imaging, biometric measurements, and corneal thickness evaluation in a single integrated platform.
It combines A-Scan, B-Scan ultrasound, and Pachymetry, making it an ideal solution for cataract evaluation, posterior segment diagnosis, glaucoma assessment, and refractive surgery planning, even in cases with opaque ocular media.
Key Features
Integrated A-Scan, B-Scan & Pachymeter in one system
High-resolution real-time ultrasound imaging
Accurate axial length and distance measurements
Precise corneal thickness (pachymetry) assessment
User-friendly interface for fast operation
Compact tabletop design with stable performance
Suitable for high-volume clinical environments
Clinical Applications
Cataract pre-operative biometry
IOL power calculation support
Posterior segment evaluation
Retinal detachment & vitreous hemorrhage detection
Intraocular mass assessment
Corneal thickness measurement (pachymetry)
Glaucoma evaluation support
Pre- and post-operative ophthalmic diagnostics
Why Choose APPA SCAN MAX-AP
Combines ultrasound and pachymetry in one platform
Reliable imaging in opaque media
Accurate biometric and corneal measurements
Cost-effective all-in-one diagnostic solution
Ideal for routine and advanced ophthalmic practice
ASCAN PROBE – TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Probe Frequency | 10 MHz |
| Fixation | Internal LED |
Measurement Range
| Parameter | Range |
|---|---|
| Axial Length | 12.0 mm to 40.0 mm |
| Anterior Chamber Depth (ACD) | 2.0 mm to 6.0 mm |
| Lens Thickness | 2.0 mm to 7.5 mm |
Measurement Accuracy
| Parameter | Specification |
|---|---|
| Accuracy | ± 0.1 mm |
Measurement Techniques
| Parameter | Specification |
|---|---|
| Method | Immersion / Contact |
| Mode | Auto / Manual |
Lens Type Compatibility
Aphakic
Phakic
Dense Cataract
Pseudo Acrylic
Pseudo Silicone
Silicon Filled
IOL Calculation
| Parameter | Specification |
|---|---|
| Supported Formulae | SRK-T, SRK-II, Holladay, Binkhorst, Hoffer-Q* , Haigis |
| Additional Formulae | One-Go Formulae, Post-Refractive Formulas |
| Note | *Hoffer-Q available on request |
Display & Control
| Parameter | Specification |
|---|---|
| Display | High-resolution 8-inch color touchscreen |
| User Interface | Touch screen control |
Data Storage
| Parameter | Specification |
|---|---|
| Patient Records | 100 |
| Preset Users | 10 |
| IOL Configurations | 25 |
Camp Mode
Fast measurement with IOL calculation
Single-screen workflow
Optimized for outreach & screening camps
| Parameter | Specification |
|---|---|
| Printer Type | Fast thermal printer |
| Feature | Auto cutter |
Power Requirements
| Parameter | Specification |
|---|---|
| Electrical Input | AC 100–240 V |
| Frequency | 47–63 Hz |
PACHYMETER – TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Measurement Range | 200 – 1000 microns |
| Accuracy | ± 5 microns |
| Probe Frequency | 20 MHz |
Communication
| Parameter | Specification |
|---|---|
| Interface | RS-232 (PC connectivity) |
